Main Dimensions & Performance Data

d

 25 mm

D

 62 mm

B

 17 mm

Cr

 52000 N

Cor

 43500 N

Cur

 4900 N

Reference speed

 8400 rpm

Limiting speed

 13900 rpm

Mounting dimensions

da min

 32 mm Shaft shoulder minimum diameter

r min

 1.1 mm Minimum chamfer size

D1

 51 mm Outer ring inner diameter

Da max

 55 mm Maximum diameter of housing shoulder

ra max

 1 mm Maximum pocket radius

d2

 35.2 mm Inner ring raceway diameter

Calculation coefficient

e

 0.28 Fa/Fr corresponds to different X and Y coefficients

Y1

 2.43 Axial dynamic load factor

Y2

 3.61 Axial dynamic load factor

Y0

 2.37 Axial static load factor
