r min
|
0.3 mm
|
Minimum chamfer size
|
da
|
34.5 mm
|
Installation size
|
E
|
40 mm
|
Outer ring raceway diameter
|
Db
|
35.6 mm
|
Axial Guide NK / Housing Shoulder Diameter
|
F
|
35 mm
|
Inner ring raceway diameter
|
db
|
39.4 mm
|
Axial guide NK/shaft shoulder diameter
|
s
|
0.8 mm
|
Axial displacement
|
Da
|
40.5 mm
|
Outer ring shoulder diameter
|
ra max
|
0.3 mm
|
Maximum pocket radius
|
