da min
|
91 mm
|
Minimum diameter of shaft shoulder
|
rmin
|
2 mm
|
Minimum chamfer size
|
Da max
|
129 mm
|
Maximum diameter of bearing block shoulder
|
ra max
|
2 mm
|
Maximum cavity radius
|
D2
|
123.7 mm
|
Inner diameter from recess to outer ring
|
d2
|
96.8 mm
|
Thrust washer diameter
|
