Main Dimensions & Performance Data

d

55 mm

D

120 mm

B

29 mm

Cr

83000 N

Cor

47500 N

Cur

3300 N

Reference speed

7800 rpm

Limiting speed

11000 rpm

Mounting dimensions

da min

66 mm Minimum diameter of shaft shoulder

rmin

2 mm Minimum chamfer size

Da max

109 mm Maximum diameter of bearing block shoulder

ra max

2 mm Maximum cavity radius

D2

105.3 mm Inner diameter from recess to outer ring

d2

72.5 mm Thrust washer diameter

Temperature range

Tmin

-20 °C Minimum operating temperature

Tmax

100 °C Maximum operating temperature

Calculation coefficient

f0

12.9 Calculation coefficient
